SP HOLDER DN68 H65
4099854013478
Product benefits
- Increase distance between spotlight and thermal insulation material
- Protects moisture barrier foil from hot surface of spotlight and driver
- Robust: 4-leg spacer to hold thermal insulation material
- Improved lifetime for LED and driver thanks to increased air-volume
Areas of application
- Ceilings in low energy houses
- Ceilings with thermal insulation material
Product features
- Material: fibre-reinforced polyamide PA66
- Glow Wire Test according to IEC 60695-2-12: 850 °C
- Suitable only for LEDVANCE SPOTs in 68 mm cut-out
Safety advice
- This spacer is only allowed to be used in combination with SP AIR FIX or SP AIR ADJ!
Ambient temperature range
-20…+40 °C
Body material
Polyamid (PA)
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
GTIN
4099854013478
Height
73 mm
Length
93.0 mm
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting depth
65,0 mm
Mounting diameter
68…83 mm
Mounting height
65 mm
Mounting location
Ceiling
Mounting type
Recessed
Packaging recyclability
Mostly recyclable packaging 1)
Product color
Grey
Product recyclability
Mostly recyclable product 1)
Product weight
19.00 g
Quantity of precious metals
0 mg
Quantity of rare earths
0 mg
Replaceable light source
No
Width
93.0 mm
