SP CBO DA ADJ V 6W MC 930 IP65 WT
4058075846326
Product benefits
- Color temperature adjustment via switch on the back of the spot
- Can be covered with most insulating materials
Areas of application
- Direct replacement for recessed spotlights with halogen lamps
- General illumination
- Hotel rooms and corridors
- Bars, restaurants
- Residential interiors
Product features
- Color temperature switch (CCT): 2700 K, 3000 K, 4000 K
- Can be controlled with DALI system
- DALI-2 certified
- Type of protection: IP65 (room side)
- Housing material: polycarbonate (PC)
Equipment / Accessories
- Already equipped with white round ring
- Additional cover rings separately available in round and square shape and in different colors
References / Links
- For Guarantee see
Added function
MULTI SELECT
Adjustable
Yes
Ambient temperature range
-20…+40 °C
Application environment
Indoor
Ball shot safe
No
Beam angle
60 °
Body material
Aluminum
Cable length
550 mm
Color rendering index Ra
> 90
Color temperature
2700 K / 3000 K / 4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Cover material
Plastic
Diameter
81.50 mm
Dimmable
Yes
Dimming range
5…100 %
ECG - Height
32 mm
ECG - Length
180 mm
ECG - Output ripple current
< 6 %
ECG - Width
44 mm
EPD
LEDV-00042-V01.01-EN
Flickering metric (Pst LM)
Glow Wire Test according to IEC 60695-2-12
650 °C
GTIN
4058075846326
Height
48.00 mm
Housing color
White
Inrush current
7.5 A
Inrush current time Th50
40 µs
Lifespan L70/B50 at 25 °C
50000 h 1)
Lifespan L80/B10 at 25 °C
35000 h 1)
Lifespan L90/B10 at 25 °C
19000 h
Light color (designation)
Warm Whi
Light emitting surface material
Plastic
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Low flicker
Yes
Luminaire with limited surface temperature, "D sign"
No
Luminous efficacy
90 lm/W 2)
Luminous flux
540 lm 1)
Mains frequency
50…60 Hz
Max. number of luminaires per miniature circuit breaker B16
40
Max. number of luminaires per miniature circuit breaker C10
30
Max. number of luminaires per miniature circuit breaker C16
40
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting depth
48 mm
Mounting diameter
68 mm
Mounting location
Ceiling
Mounting type
Recessed
Nominal current
35.000 mA
Nominal voltage
220…240 V
Nominal wattage
6.00 W
Number of switching cycles
25000
Operating mode
External LED driver
Output current
150 mA
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG1
Power factor λ
0.50
Product color
White
Product recyclability
Mostly recyclable product 1)
Product weight
285.00 g
Protection class
III
Protection class IK (shock resistance)
IK03
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
RAL Color (most similar)
RAL 9016
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Standard deviation of color matching
< 6 sdcm
Stroboscope effect metric (SVM)
Temperature range at storage
-20…+80 °C
Total harmonic distortion
< 35 %
Type of connection
Push terminal
Type of dimming
DALI-2
Type of protection
IP65/IP20
UGR
< 25
With light source
Yes
