SP CBO ADJ V 6W ML 9273040 DIM IP65/5X WT
4099854736490
Product benefits
- Easy color temperature adjustment via switch on the front of the spot
- Multi Lumen: Brightness adjustment via a switch on the front of the spot
- Can be covered with most insulating materials
Areas of application
- Direct replacement for recessed spotlights with halogen lamps
- General illumination
- Hotel rooms and corridors
- Bars, restaurants
- Residential interiors
Product features
- Color temperature switch (CCT): 2700 K, 3000 K, 4000 K
- Type of protection: IP65 (front side) and IP50 (back side)
- Housing material: polycarbonate (PC)
- Ring colors in white matt or anodized aluminum
- Dimmable (with many common dimmers)
Equipment / Accessories
- Already equipped with white round ring
- Additional cover rings separately available in round and square shape and in different colors
- Security rope for luminaire included
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be effectively fixed to the wall if the wiring is within arm’s reach.
References / Links
- For Guarantee see
4.3 W
95 lm/W
6 W
95 lm/W
Added function
MULTI SELECT
Adjustable
Yes
Ambient temperature range
-20…+40 °C
Application environment
Indoor
Ball shot safe
No
Beam angle
60 °
Body material
Aluminum|Polycarbonate (PC)
Cable length
600 mm
Color rendering index Ra
> 90
Color temperature
2700 K / 3000 K / 4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Cover material
Plastic
Diameter
82.00 mm
Dimmable
Yes
ECG - Height
25,5 mm
ECG - Length
76 mm
ECG - Output ripple current
≤ 6 %
ECG - Width
30 mm
Flickering metric (Pst LM)
Glow Wire Test according to IEC 60695-2-12
850 °C
GTIN
4099854736490
Height
41.00 mm
Housing color
Black
Inrush current
0.76 A
Inrush current time Th50
100 µs
Lifespan L70/B50 at 25 °C
50000 h 1)
Lifespan L80/B10 at 25 °C
40000 h 1)
Lifespan L90/B10 at 25 °C
18000 h
Light color (designation)
Warm Whi
Light emitting surface material
Plastic
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Low flicker
Yes
Luminaire with limited surface temperature, "D sign"
No
Luminous efficacy
100 lm/W / 95 lm/W
Luminous flux
600 lm / 570 lm / 430 lm / 410 lm
Luminous intensity
590 cd
Mains frequency
50…60 Hz
Max. number of luminaires per miniature circuit breaker B16
64
Max. number of luminaires per miniature circuit breaker C10
40
Max. number of luminaires per miniature circuit breaker C16
64
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting depth
38 mm
Mounting diameter
68 mm
Mounting location
Ceiling
Mounting type
Recessed
Nominal current
27…21 mA
Nominal voltage
220…240 V
Nominal wattage
6 W / 4.3 W
Number of switching cycles
25000
Operating mode
External LED driver
Output current
160 mA
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG1
Power factor λ
≥ 0.90
Product color
White
Product recyclability
Mostly recyclable product 1)
Product remark
Available from March 2026
Product weight
250.00 g
Protection class
II
Protection class IK (shock resistance)
IK03
RAL Color (most similar)
RAL 9003
Reference control setting of contained light source (Kelvin)
2700 K
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Standard deviation of color matching
6 sdcm
Stroboscope effect metric (SVM)
Temperature range at storage
-20…+80 °C
Total harmonic distortion
< 35 %
Type of connection
Push terminal
Type of emergency operation test
None
Type of protection
IP65/IP50
With light source
Yes
