SP CBO ADJ DA V 6W ML 9273040 IP65 WT
4099854736551
Product benefits
- Easy color temperature adjustment via switch on the front of the spot
- Multi Lumen: Brightness adjustment via a switch on the front of the spot
- Can be covered with most insulating materials
Areas of application
- Direct replacement for recessed spotlights with halogen lamps
- General illumination
- Hotel rooms and corridors
- Bars, restaurants
- Residential interiors
Product features
- Color temperature switch (CCT): 2700 K, 3000 K, 4000 K
- Type of protection: IP65
- Housing material: polycarbonate (PC)
- Ring colors in white matt or anodized aluminum
- Can be controlled with DALI system
- DALI-2 certified
- Dimmable (with many common dimmers)
Equipment / Accessories
- Already equipped with white round ring
- Additional cover rings separately available in round and square shape and in different colors
- Security rope for luminaire included
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be effectively fixed to the wall if the wiring is within arm’s reach.
- The luminaires are not suitable for covering with thermally insulated material.
References / Links
- For Guarantee see
4.3 W
90 lm/W
6 W
90 lm/W
Added function
MULTI SELE
Adjustable
Yes
Ambient temperature range
-20…+40 °C
Application environment
Indoor
Ball shot safe
No
Beam angle
60 °
Body material
Aluminum|Polycarbonate (PC)
Cable length
600 mm
Color rendering index Ra
> 90
Color temperature
2700 K / 3000 K / 4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Cover material
Plastic
Diameter
82.00 mm
Dimmable
Yes
Dimming range
1…100 %
ECG - Height
25,0 mm
ECG - Length
164 mm
ECG - Output ripple current
≤ 10 %
ECG - Width
45,0 mm
Flickering metric (Pst LM)
Glow Wire Test according to IEC 60695-2-12
650 °C
GTIN
4099854736551
Height
41.00 mm
Housing color
Black
Inrush current
5.13 A
Inrush current time Th50
26 µs
IoT ready
Support of DALI data type PART 251, 252, 253 1)
Lifespan L70/B50 at 25 °C
50000 h 1)
Lifespan L80/B10 at 25 °C
40000 h 1)
Lifespan L90/B10 at 25 °C
18000 h
Light color (designation)
Warm Whi
Light emitting surface material
Plastic
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Low flicker
Yes
Luminaire with limited surface temperature, "D sign"
No
Luminous efficacy
95 lm/W / 90 lm/W
Luminous flux
570 lm / 540 lm / 410 lm / 400 lm
Luminous intensity
530 cd
Mains frequency
50…60 Hz
Max. number of luminaires per miniature circuit breaker B16
64
Max. number of luminaires per miniature circuit breaker C10
40
Max. number of luminaires per miniature circuit breaker C16
64
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting depth
38 mm
Mounting diameter
68 mm
Mounting location
Ceiling
Mounting type
Recessed
Nominal current
36…30 mA
Nominal voltage
220…240 V
Nominal wattage
6 W / 4.3 W
Number of switching cycles
25000
Operating mode
External LED driver
Output current
150 mA
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG1
Power factor λ
≥0.5
Product color
White
Product recyclability
Mostly recyclable product 1)
Product remark
Available from March 2026
Product weight
279.00 g
Protection class
II
Protection class IK (shock resistance)
IK03
RAL Color (most similar)
RAL 9003
Reference control setting of contained light source (Kelvin)
2700 K
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Standard deviation of color matching
6 sdcm
Stroboscope effect metric (SVM)
Temperature range at storage
-20…+80 °C
Total harmonic distortion
< 35 %
Type of connection
Push terminal
Type of dimming
DALI-2
Type of emergency operation test
None
Type of protection
IP65/IP20
With light source
Yes
