SL AREA SPD LA V 90W 727 RV35ST GY
4099854079801
Product benefits
- Functional and minimalistic design
- Low maintenance and operation costs due to long lifetime of LED
- 5 years guarantee
Areas of application
- Outdoor use (IP66)
- M-, C- and P-class roads acc. to EN 13201
- Car parks
- Area lighting
Product features
- Light distributions optimized for streets of similar width to the pole height
- Spigot included, suitable for 48…60 mm diameter poles
- Adjustable spigot for both side-entry and post-top installation
- +/- 30° tilt angle adjustment without opening the housing
- High luminous efficacy: up to 135 lm/W
- Operating temperature: -30...50 °C
- High surge protection: up to 10 kV (L/N-PE)
Adjustable
Yes
Ambient temperature range
-30…+50 °C
Application environment
Outdoor
Ball shot safe
No
Beam angle
155° x 69°
Body material
Aluminum
Cable length
500 mm
Color rendering index Ra
70
Color temperature
2700 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Cover material
Polycarbonate (PC)
Dimmable
No
ECG - Output ripple current
< 5 %
Glow Wire Test according to IEC 60695-2-12
650 °C
GTIN
4099854079801
Height
73.00 mm
Housing color
Gray
Inrush current
9.8 A
Inrush current time Th50
360 µs
Length
473.00 mm
Lifespan L70/B50 at 25 °C
100000 h 1)
Lifespan L80/B10 at 25 °C
70000 h 1)
Lifespan L90/B10 at 25 °C
30000 h
Light color (designation)
Warm White
Light emitting surface material
Polycarbonate (PC)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Low flicker
Yes
Luminaire with limited surface temperature, "D sign"
No
Luminous efficacy
130 lm/W
Luminous flux
11700 lm
Mains frequency
50…60 Hz
Max. number of luminaires per miniature circuit breaker B16
28
Max. number of luminaires per miniature circuit breaker C10
18
Max. number of luminaires per miniature circuit breaker C16
30
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting location
Pole
Mounting type
Side entry|post top
Nominal current
420.000 mA
Nominal voltage
100…240 V
Nominal wattage
90.00 W
Number of switching cycles
100000
Operating mode
Integrated LED driver
Output current
510 mA
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62471
RG1
Photobiological safety group acc. to EN62778
RG1
Power factor λ
> 0.90
Product color
Gray
Product recyclability
Mostly recyclable product 1)
Product weight
3200.00 g
Protection class
I
Protection class IK (shock resistance)
IK08
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Standard deviation of color matching
< 5 sdcm
Temperature range at storage
-30…+80 °C
Total harmonic distortion
< 20 %
Type of connection
Cable, 3-pole
Type of connection for sensor/communication module
Other
Type of protection
IP66
Width
260.00 mm
With light source
Yes
