LISOEV 330 SQ 19W 830 840 SF FLAT
4099854312250
Product benefits
- 3000 K and 4000 K LEDs integrated
- Indoor use with high luminous efficacy of up to 140 lm/W
- High color consistency with SDCM 3
- Tool-free electrical connection with plug connectors
- Very homogenous light with a slight backlight effect
- Prepared for SURFACE FLAT SENSOR integration
- 5 years guarantee
Areas of application
- Suitable for SURFACE FLAT 19 W / 27 W
Product features
- Type of protection: IP20
- Polycarbonate (PC) housing, PC-diffuser
- Lifetime (L80/B10): 100,000 h (at 25 °C), (L90/B10): 50,000 h (at 25 °C)
- Impact resistance: IK08
- Glow Wire Test according to IEC 60695-2-12: 850 °C
- Indoor use only, not suitable for outdoor use
Equipment / Accessories
- Connection wire for direct installation integrated
References / Links
- For Guarantee see
Added function
EVERLO
Ambient temperature range
-20…+45 °C
Beam angle
120 °
Body material
Polycarbonate (PC)
Color rendering index Ra
> 80
Color temperature
3000 K / 4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Dimmable
No
GTIN
4099854312250
Height
53.00 mm
Housing color
White
Length
330.00 mm
Lifespan L70/B50 at 25 °C
10000 h
Lifespan L80/B10 at 25 °C
100000 h
Lifespan L90/B10 at 25 °C
50000 h
Light color (designation)
Warm Whi
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Luminous efficacy
140 lm/W
Luminous flux
2660 lm
Mains frequency
50…60 Hz
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting type
Surface
Nominal current
450 mA
Nominal voltage
30…40 V
Nominal wattage
16.0 W
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG0
Product color
White
Product recyclability
Mostly recyclable product 1)
Product weight
1038.00 g
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
Replaceable light source (EPREL)
Not replaceable
Standard deviation of color matching
3 sdcm
Standards
CE
Temperature range at storage
-40…+80 °C
Type of protection
IP20
Width
330.00 mm
