HB SEN P 147W 840 70DEG IP65
4058075603271
Product benefits
- Multiple adjustments of sensor range, daylight detection and hold time
- High luminous efficacy
- Energy savings of up to 64 % compared to conventional high bay luminaires
- 5 years guarantee
- Suitable for use in dusty and damp locations thanks to high IP rating
Areas of application
- Replacement for high bay luminaires with mercury vapor or metal halide lamps
- Warehouses
- Logistics halls
- Industry
- High ceiling (e.g. in shopping malls, airports, commercial buildings, lobbies)
Product features
- High frequency sensor for daylight and motion detection
- Different luminous flux and beam angle for mounting heights of ~ 6 m to 10 m in 4000 K
Equipment / Accessories
- Sensor, mounting hook and mounting bracket included
- Reflectors, refractors and remote control available as separate accessory
References / Links
- For Guarantee see
Ambient temperature range
-20…+50 °C
Application environment
Indoor
Ball shot safe
No
Beam angle
70 °
Body material
Aluminum
Cable length
1500 mm
Color rendering index Ra
≥80
Color temperature
4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Cover material
Polycarbonate (PC)
Detection range of motion sensor
6…15 m
Detection threshold of daylight sensor
100 lx
Diameter
321.00 mm
Dimmable
No
ECG - Output ripple current
< 10 %
EPD
LEDV-00024-V01.01-EN
Glow Wire Test according to IEC 60695-2-12
850 °C
GTIN
4058075603271
Height
188.00 mm
Housing color
Black
Inrush current
48.8 A
Inrush current time Th50
368 µs
Lifespan L70/B50 at 25 °C
80000 h 1)
Lifespan L80/B10 at 25 °C
50000 h 1)
Lifespan L90/B10 at 25 °C
35000 h
Light color (designation)
Cool White
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Additional info can be provided per individual request
Low flicker
Yes
Luminaire with limited surface temperature, "D sign"
Yes
Luminous efficacy
150 lm/W
Luminous flux
22000 lm
Mains frequency
50…60 Hz
Max. number of luminaires per miniature circuit breaker B16
4
Max. number of luminaires per miniature circuit breaker C10
4
Max. number of luminaires per miniature circuit breaker C16
6
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting location
Ceili
Mounting type
Surface/Suspended
Nominal current
660 mA
Nominal voltage
220…240 V
Nominal wattage
147.00 W
Number of switching cycles
200000
Operating mode
Mains voltage
Packaging recyclability
Mostly recyclable packaging 1)
Power factor λ
> 0.95
Product color
Black
Product recyclability
Mostly recyclable product 1)
Product weight
2690.00 g
Protection class
I
Protection class IK (shock resistance)
IK08
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Sensor controlled switching time
30s…10 min
Sensor detection angle
< 150 °
Sensor technology
Microwave
Standard deviation of color matching
< 5 sdcm
Temperature range at storage
-40…+70 °C
Total harmonic distortion
< 20 %
Type of connection
Cables
Type of protection
IP65
Type of sensor
Moti
UGR
≤ 25
With light source
Yes
