HB DALI 155 W 4000 K 110DEG IP65
4058075543928
Product benefits
- High compatibility thanks to DALI-2 certification
- DALI 2.0 interface for dimming and sensor operations
- Low flicker light thanks to special electronic control gear
- High luminous efficacy
- Energy savings of up to 90 % compared to conventional high bay luminaires
- 5 years guarantee
Areas of application
- Replacement for high bay luminaires with mercury vapor or metal halide lamps
- Warehouses
- Logistics halls
- Industry
- High ceiling (e.g. in shopping malls, airports, commercial buildings, lobbies)
Product features
- Pre-configured DALI driver included
- Luminous efficacy: up to 140 lm/W
- Type of protection: IP65
- Dimming range (DALI): 10…100 %
Equipment / Accessories
- Mounting hook and brackets included
- Reflectors and refractors available as separate accessory
References / Links
- For Guarantee see
Adjustable
Yes
Ambient temperature range
-30…+50 °C
Application environment
Indoor
Ball shot safe
No
Beam angle
110 °
Body material
Aluminum
Color rendering index Ra
≥80
Color temperature
4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Cover material
Polycarbonate (PC)
Diameter
321.00 mm
Dimmable
Yes
ECG - Output ripple current
< 10 %
EPD
LEDV-00021-V01.01-EN
Glow Wire Test according to IEC 60695-2-12
850 °C
GTIN
4058075543928
Height
163.00 mm
Housing color
Black
Inrush current
60.4 A
Inrush current time Th50
312 µs
Lifespan L70/B50 at 25 °C
80000 h 1)
Lifespan L80/B10 at 25 °C
50000 h 1)
Lifespan L90/B10 at 25 °C
30000 h
Light color (designation)
Cool White
Light emitting surface material
Polycarbonate (PC)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Low flicker
Yes
Luminaire with limited surface temperature, "D sign"
Yes
Luminous efficacy
140 lm/W
Luminous flux
22000 lm
Mains frequency
50…60 Hz
Max. number of luminaires per miniature circuit breaker B16
3
Max. number of luminaires per miniature circuit breaker C10
3
Max. number of luminaires per miniature circuit breaker C16
5
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting location
Ceili
Mounting type
Suspended/Surface
Nominal current
700 mA
Nominal voltage
100…277 V
Nominal wattage
155.00 W
Number of switching cycles
200000
Operating mode
Mains voltage
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG1
Power factor λ
≥0.95
Product color
Black
Product recyclability
Mostly recyclable product 1)
Product weight
3568.00 g
Protection class
I
Protection class IK (shock resistance)
IK08
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
RAL Color (most similar)
RAL 9017
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Standard deviation of color matching
< 5 sdcm
Temperature range at storage
-40…+70 °C
Total harmonic distortion
< 20 %
Type of connection
2 Cables (2-pole/3-pole)
Type of dimming
DALI
Type of protection
IP65
UGR
< 25
With light source
Yes
