DR DS-V 30/220-240/800 PL COMP
4099854748837
Product benefits
- Highly versatile due to selectable mA output (30 W, 42 W driver)
- Low flickering enables high light quality as well as good visual comfort
- High efficiency and reliability
- Through-wiring possible
- For cable cross sections up to 3 x 1,5 mm
Areas of application
- Suitable for use with PANEL COMPACT 26 W, 30 W or 42 W
Product features
- Available as 26 W, 30 W and 42 W version
- Protection class: II
- Type of protection: IP20
- Supply voltage: 220…240 V
- Operating frequency: 50/60 Hz
References / Links
- For Guarantee see
Ambient temperature range
-10…+45 °C
Body material
Polycarbonate (PC)
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Additional info can be provided per individual request
Dimmable
No
ECG lifetime
100000 h
GTIN
4099854748837
Height
30.00 mm
Inrush current
0.135 A
Length
175.00 mm
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Mains frequency
50/60 Hz
Max. number of luminaires per miniature circuit breaker B16
25
Max. number of luminaires per miniature circuit breaker C16
30
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Nominal current
135mA / 115mA / 105 mA
Nominal output current
800
Nominal voltage
220…240 V
Nominal wattage
30 W / 26 W / 22 W
Number of switching cycles
100000
Packaging recyclability
Mostly recyclable packaging 1)
Power factor λ
> 0.90
Product color
White
Product recyclability
Mostly recyclable product 1)
Product remark
Available from March 2026
Product weight
130.00 g
Protection class
II
RAL Color (most similar)
RAL9003
Surge capability (L-N)
1 kV
Surge capability (L/N-Ground)
1 kV
Temperature range at storage
-20…+80 °C
Total harmonic distortion
20 %
Type of protection
IP20
Width
55.00 mm
