DP SLIM 600 V 14W ML 865 IP65
4099854720215
Product benefits
- Uniform light distribution
- Energy savings of up to 65 % (compared to luminaires that use fluorescent lamps)
- Very slim housing
- Easy installation as mounting brackets can be positioned freely on the luminaire
- Tool-free electrical connection due to push button connector
- 5 years guarantee
- Easy access to electrical terminal thanks end caps with clip mechanism
Areas of application
- Industrial and storage facilities
- Car parks and underpasses
- Garages
- Workshops, assembly lines
Product features
- High luminous efficacy: up to 140 lm/W
- Lifetime (L80/B10): up to 50,000 h (at 25 °C)
- Housing and diffuser material: polycarbonate (PC)
- Multi Lumen function: lumen steps selectable
- Beam angle: 120°
- Type of protection: IP65
Equipment / Accessories
- Stainless steel clamps with safety screws included
- Mounting accessories included (suspension kit, theft protection kit)
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
References / Links
- For Guarantee see
14 W
140 lm/W
9 W
140 lm/W
Added function
MULTI SELECT
Adjustable
No
Ambient temperature range
-20…+40 °C
Application environment
Indoor
Ball shot safe
No
Beam angle
120 °
Body material
Polycarbonate (PC)
Color rendering index Ra
> 80
Color temperature
6500 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Cover material
Polycarbonate (PC)
Dimmable
No
ECG - Output ripple current
< 5 %
EPD
LEDV-00077-V01.01-EN
Flickering metric (Pst LM)
< 1
Glow Wire Test according to IEC 60695-2-12
650 °C
GTIN
4099854720215
Height
48.00 mm
Housing color
White
Inrush current
14.95 A
Inrush current time Th50
129 µs
Length
635.00 mm
Lifespan L70/B50 at 25 °C
50000 h 1)
Lifespan L80/B10 at 25 °C
50000 h 1)
Lifespan L90/B10 at 25 °C
50000 h
Light color (designation)
Cool Daylight
Light emitting surface material
Polycarbonate (PC)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Low flicker
Yes
Luminaire with limited surface temperature, "D sign"
Yes
Luminous efficacy
140 lm/W
Luminous flux
2000 lm / 1300 lm
Mains frequency
50…60 Hz
Max. number of luminaires per miniature circuit breaker B16
40
Max. number of luminaires per miniature circuit breaker C10
32
Max. number of luminaires per miniature circuit breaker C16
51
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting height
0 m
Mounting location
Ceili
Mounting type
Surface
Nominal current
63.000 mA
Nominal voltage
220…240 V
Nominal wattage
14 W / 9 W
Number of switching cycles
100000
Operating mode
Integrated LED driver
Output current
95 mA
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG0
Power factor λ
> 0.80
Product color
White
Product recyclability
Mostly recyclable product 1)
Product remark
Available from March 20
Product weight
240.00 g
Protection class
II
Protection class IK (shock resistance)
IK08
RAL Color (most similar)
RAL 9016
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Standard deviation of color matching
5 sdcm
Stroboscope effect metric (SVM)
< 0.4
Surge capability (L-N)
1 kV
Temperature range at storage
-20…+80 °C
Total harmonic distortion
< 20 %
Type of connection
Screwless terminal, 2-Pole
Type of emergency operation test
None
Type of protection
IP65
Width
35.00 mm
With light source
Yes
