BLKH COMP RC V 8W ML 83040 BK
4099854290480
Product benefits
- Versatile due to selectable CCT in 3000K and 4000K
- Highly versatile due to selectable lumen steps (Multi Lumen) on the driver
- Suitable for use in dusty and damp locations thanks to high IP rating
- Suitable for use in public areas thanks to high IK rating
- Multiple mounting patterns for convenient installation
Areas of application
- Direct replacement for luminaires with fluorescent lamps
- Corridors, stairways, entrance areas
- Passages, underpasses
- Public areas
Product features
- Housing and cover made of UV-resistant PC
- Type of protection: IP65
- Impact resistance: IK10
- Luminous flux: up to 840 lm
- Lifetime (L70/B50) up to 50,000 h (at 25 °C)
- Ambient temperature in operation: -20…+45 °C
- Push wire terminal for tool-free connection
- Through-wiring possible
Equipment / Accessories
- Mounting screws and dowels included
- Anti-theft screw included
References / Links
- For Guarantee see
Added function
MULTI SELECT
Ambient temperature range
-20…+45 °C
Application environment
Outdoor
Ball shot safe
No
Beam angle
125 °
Body material
Polycarbonate (PC)
Color rendering index Ra
> 80
Color temperature
3000 K / 4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Cover material
Polycarbonate (PC)
Dimmable
No
ECG - Output ripple current
< 5 %
EPD
LEDV-00052-V01.01-EN
Flickering metric (Pst LM)
Glow Wire Test according to IEC 60695-2-12
850 °C
GTIN
4099854290480
Height
80.00 mm
Housing color
Black
Inrush current
4 A
Inrush current time Th50
180 µs
Length
356.00 mm
Lifespan L70/B50 at 25 °C
50000 h 1)
Lifespan L80/B10 at 25 °C
40000 h 1)
Lifespan L90/B10 at 25 °C
20000 h
Light color (designation)
Warm Whi
Light emitting surface material
Polycarbonate (PC)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Low flicker
Yes
Luminaire with limited surface temperature, "D sign"
No
Luminous efficacy
105 lm/W / 115 lm/W / 125 lm/W 1)
Luminous flux
840 lm / 690 lm / 500 lm 1)
Mains frequency
50/60 Hz
Max. number of luminaires per miniature circuit breaker B16
104
Max. number of luminaires per miniature circuit breaker C10
87
Max. number of luminaires per miniature circuit breaker C16
140
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting location
Ceili
Mounting type
Surface
Nominal current
42…31…22 mA
Nominal voltage
220…240 V
Nominal wattage
8 W / 6 W / 4 W 1)
Number of switching cycles
100000
Operating mode
Integrated LED driver
Output current
220…165…115 mA
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG0
Power factor λ
> 0.7
Product color
Black
Product recyclability
Mostly recyclable product 1)
Product weight
540.00 g
Protection class
II
Protection class IK (shock resistance)
IK10
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
RAL Color (most similar)
RAL 9005
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Standard deviation of color matching
5 sdcm
Stroboscope effect metric (SVM)
Temperature range at storage
-20…+80 °C
Total harmonic distortion
< 64 %
Type of connection
Screwless terminal
Type of protection
IP65
Width
115.00 mm
With light source
Yes
