Product benefits

Simple integration of non-dimmable luminaires in DALI systems
Configurable Power-Up behaviour
Integrated current limiter
Over temperature protection for save operation
Supports over voltage protection for long product lifetime
Zero cross switching
Compatible with LEDVANCE VIVARES DALI light management system

Areas of application

Integration of non-dimmable luminaires in DALI lighting systems (DT7)

Product features

Pre-mounted endcap with strain relief function for flexible product installations
Suitable for high inrush currents up to 350 A
Fulfills the requirements for DALI Device Type 7 - switching function
Switching of non-dimmable loads up to 16 A via DALI
Suitable for loads with high inrush current

Safety advice

All electrical connections must be made by a qualified person.
Caution, risk of electric shock.

References / Links

For current information see

Ambient temperature range

-20…+60 °C

Body material

Polycarbonate (PC)

Cable cross-section, input side

0.5…1.5 mm²

Cable cross-section, output side

0.5…2.5 mm²

Contains substances of very high concern in concentrations greater than 0.1% by mass percentage

No

Dimmable

Yes

Dimming interface

DALI-2

GTIN

4099854709135

Height

22.00 mm

Inrush current

350 A

Length

120.00 mm

List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage

No

Mains frequency

50…60 Hz

Maximum temperature at tc test point

65 °C

Minimum percentage of recycled content in the product

0 % 1)

Minimum rate of recycled material in packaging

80 % 1)

Nominal current

16 A

Nominal voltage

230 V

Nominal wattage

3000.00 W

Number of control outputs

1

Number of switching cycles

100000

Over voltage protection

Yes

Overheating protection

Reversible

Packaging recyclability

Mostly recyclable packaging 1)

Product color

White

Product recyclability

Mostly recyclable product 1)

Product remark

Available from December 2025

Product weight

54.00 g

Protection class

II

Reverse polarity protection

Yes

Temperature range at storage

-20…+75 °C

Type of current

AC

Type of installation

Independent mounting

Type of protection

IP20

Width

30.00 mm

Wire preparation length, input side

8.5…9.5 mm

Wire preparation length, output side
