DIM MCU
4050300347424
Product benefits
- Intuitive manual dimming and switching
- Individual setting of minimal brightness level
Areas of application
- Conference rooms
- Restaurants
- Shop lighting
Product features
- Switching load contact: 250 V/6 A (10 1-lamp or 5 2-lamp ECGs)
- Cover and rotary knob in cream white
Equipment / Accessories
- Suitable for up to 50 electronic control gears (external load contact required)
- Flexible expansion via external load contact and via signal amplifier DIM SA
- Cover and rotary knob included
Ambient temperature range
0…+50 °C
Approval marks – approval
CE
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Diameter
54 mm
Dimmable
Yes
Dimming interface
1…10 V
Energy efficiency class
A1
GTIN
4050300347424
Height
40.00 mm
Length
80.00 mm
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Load contact
6 A
Mains frequency
50/60 Hz
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting hole spacing, length
70,0 mm
Nominal voltage
230 V
Number of control outputs
1
Overheating protection
No
Packaging recyclability
Mostly recyclable packaging 1)
Product color
Cream white
Product recyclability
Mostly recyclable product 1)
Product weight
140.00 g
Protection class
II
Quantity of precious metals
0 mg
Quantity of rare earths
0 mg
Type of installation
Integrated in flush device box
Type of protection
IP20
Width
80.00 mm
