LS VAL -600/865/5
4058075296992
Product benefits
- Great scope of design options due to long and flexible LED strips
- Easy mounting on many smooth surfaces thanks to self-adhesive tape
- Maximum flexibility due to large range of accessories
- Simple connection thanks to integrated cables on both sides
Areas of application
- General indoor illumination
- Decorative illumination
- Private living areas
Product features
- Flexible and cuttable LED strip
- Smallest cuttable unit: 100 mm
- Lifetime (L70/B50): up to 20,000 h at Tc max.: 65°C
- Luminous flux: 600 lm/m
- Color rendering index Ra: > 80
- Available with light color: Warm White, White, Daylight
- Dimmable with suitable drivers, see also
Safety advice
- All electrical connections must be made by a qualified person.
Ambient temperature range
-20…+40 °C 1)
Approval marks – approval
Ro
Beam angle
120 °
Cable length
500.000
Color rendering index Ra
> 80
Color temperature
6500 K
Conductor cross section
0.5 mm²
Construction wattage
27.00 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Dimmable
Yes 1)
Energy consumption
6.05 kWh/1000h 1)
Energy efficiency class
A+
GTIN
4058075296992
Height
1.30 mm
Input voltage range
23…25 V 2)
LED pitch
16.67 mm
Length
5000.00 mm
Length – smallest unit
100 mm
Light color (designation)
Cool Daylight
Light color LED
Daylight
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Lowest bending radius
30 mm
Luminous efficacy
105 lm/W 1)
Luminous flux
2533 lm
Luminous flux per meter
580 lm 1)
Luminous flux per module chain
2533 lm
Maximum temperature at tc test point
65 °C 2)
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Nominal current
1042.000 mA
Nominal lamp life time
20000 h
Nominal voltage
24 V 2)
Nominal wattage
27.00 W
Nominal wattage per meter
5.5 W 1)
Number of LEDs per meter
60
Number of LEDs per module
300
Number of LEDs per smallest unit
6
Packaging recyclability
Mostly recyclable packaging 1)
Prewired
Yes
Product recyclability
Mostly recyclable product 1)
Product weight
64.00 g
Rated beam angle (half peak value)
115.00 °
Reverse polarity protection
Up to maximum 25 VDC
Reverse Voltage
25 V 2)
Salt mist resistance acc. IEC 60068-2-52
No
Self-adhesive
Yes
Short pitch
No
Standard deviation of color matching
≤6 sdcm
Standards
Acc. to IEC 624
Temperature range at storage
-20…+85 °C
Temperature range in operation
-20…+65 °C 3)
Total useful luminous flux [PICOS]
580 lm
Type of current
DC
Type of protection
IP00
UV resistance acc. IEC 60068-2-5
No
Width
8.00 mm
