LS PFM -1000/COB/965/5
4058075597556
Product benefits
- Excellent homogenous light, without visible light points thanks to COB technology
- Great design freedom thanks to flexibility and cuttability of module
- Easy mounting on many smooth surfaces thanks to self-adhesive tape at the back
- Simple connection thanks to integrated cables on both sides
- Maximum flexibility due to large range of accessories
- Easy installation, no tools required for connection
Areas of application
- General illumination
- Cove lighting
- Bars, restaurants, hotels
- Offices
- Residential interiors
Product features
- Flexible and cuttable LED strip
- Luminous flux: 1000 lm/m
- Very good color rendering index Ra: > 90
- Smallest cuttable unit: 62.5 mm
- Large range of color temperatures: from warm white to cool daylight
- Dimmable with suitable drivers, see also
Equipment / Accessories
- Connectors, profiles and covers for several mounting options available
Ambient temperature range
-20…+55 °C
Beam angle
140 °
Cable length
500.000
Color rendering index Ra
> 90
Color temperature
6500 K
Conductor cross section
0.5 mm²
Construction wattage
38.00 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Dimmable
Yes 1)
Energy class of contained light source
F
Energy consumption
5.50 kWh/1000h 1)
GTIN
4058075597556
Height
1.70 mm
Input voltage range
23…25 V
Length
5000.00 mm
Length – smallest unit
62.5 mm
Light color (designation)
6500 K
Light color LED
Daylight
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Lowest bending radius
10 mm
Luminous efficacy
98 lm/W 1)
Luminous flux
3500 lm
Luminous flux per meter
1060 lm 1)
Maximum temperature at tc test point
75 °C
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Nominal current
1600 mA
Nominal lamp life time
50000 h
Nominal voltage
24 V
Nominal wattage
38.00 W
Nominal wattage per meter
11.0 W 1)
Number of LEDs per meter
384
Number of LEDs per module
384
Number of LEDs per smallest unit
24
Packaging recyclability
Mostly recyclable packaging 1)
Prewired
Yes
Product recyclability
Mostly recyclable product 1)
Product weight
188.00 g
Protection class
III
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
Reverse Voltage
144 V
Salt mist resistance acc. IEC 60068-2-52
No
Self-adhesive
Yes
Short pitch
Yes
Standard deviation of color matching
≤5 sdcm
Temperature range at storage
-40…+85 °C
Temperature range in operation
-20…+55 °C
Type of current
DC
Type of protection
IP00
UV resistance acc. IEC 60068-2-5
No
Width
8.00 mm
