LS PFM -1000/865/5/IP66
4058075236103
Product benefits
- Great scope of design options due to long and flexible LED strips
- Easy installation, no tools required for connection
- Easy mounting on many smooth surfaces thanks to self-adhesive tape
- Suitable for use in damp conditions thanks to high type of protection
- Maximum flexibility due to large range of accessories
- Simple connection thanks to integrated cables on both sides
Areas of application
- General indoor illumination
- General outdoor illumination
- Industry
- Offices, retail outlets and conference rooms
- Architecture lighting
Product features
- Flexible and cuttable LED strip
- Smallest cuttable unit: 100 mm
- Lifetime (L70/B50): up to 35,000 h at Tc max.: 75°C
- Luminous flux: 1000 lm/m
- Color rendering index Ra: > 80
- Initial color consistency: ≤ 4 SDCM
- Large range of color temperatures: from warm white to cool daylight
- Type of protection: IP66
- Dimmable with suitable drivers, see also
- UV restistance (acc. IEC 60068-2-5)
- Salt mist resistance (acc. IEC 60068-2-52)
Equipment / Accessories
- Connectors, profiles and covers for several mounting options available
- Endcaps have to be ordered separately
Safety advice
- All electrical connections must be made by a qualified person.
Ambient temperature range
-15…+45 °C 1)
Approval marks – approval
T
Beam angle
105 °
Cable length
500.000
Color rendering index Ra
> 80
Color temperature
6500 K
Conductor cross section
0.5 mm²
Construction wattage
40.50 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Cover material
Silicone
Dimmable
Yes 1)
Energy consumption
44.55 kWh/1000h
Energy efficiency class
A+
GTIN
4058075236103
Height
4.50 mm
Input voltage range
23…25 V 1)
LED pitch
14.3 mm
Length
5000.00 mm
Length – smallest unit
100 mm
Light color (designation)
Cool Daylight
Light color LED
Daylight
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Lowest bending radius
25 mm
Luminous efficacy
117.3 lm/W
Luminous flux
4750 lm
Luminous flux per meter
950 lm
Luminous flux per module chain
4750 lm
Maximum temperature at tc test point
75 °C 2)
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Nominal current
1687.000 mA
Nominal lamp life time
35000 h
Nominal voltage
24 V 1)
Nominal wattage
40.50 W
Nominal wattage per meter
8.1 W
Number of LEDs per meter
70
Number of LEDs per module
350
Number of LEDs per smallest unit
7
Number of switching cycles
100,000
Packaging recyclability
Mostly recyclable packaging 1)
Prewired
Yes
Product recyclability
Mostly recyclable product 1)
Product weight
285.00 g
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
Reverse polarity protection
Up to maximum 25 VDC
Reverse Voltage
25 V 1)
Salt mist resistance acc. IEC 60068-2-52
Yes
Self-adhesive
Yes
Short pitch
No
Standard deviation of color matching
≤4 sdcm
Standards
Acc. to IEC 624
Temperature range at storage
-35…+85 °C
Temperature range in operation
-15…+75 °C 3)
Type of current
DC
Type of protection
IP66
UV resistance acc. IEC 60068-2-5
Yes
Width
10.00 mm
