LS P -500/965/5
4058075707535
Product benefits
- Great scope of design options due to long and flexible LED strips
- Easy installation, no tools required for connection
- Maximum flexibility due to large range of accessories
- Simple connection thanks to integrated cables on both sides
Areas of application
- General indoor illumination
- Industry
- Offices, retail outlets and conference rooms
- Architecture lighting
- Decorative illumination
Product features
- Flexible and cuttable LED strip
- Smallest cuttable unit: 55.56 mm
- Lifetime (L70/B50): up to 50,000 h at Tc max.: 80°C
- Luminous flux: 500 lm/m
- Very good color rendering index Ra: > 90
- Initial color consistency: < 3 SDCM
- Large range of color temperatures: from warm white to cool daylight
- Dimmable with suitable drivers, see also
Equipment / Accessories
- Connectors, profiles and covers for several mounting options available
Ambient temperature range
-20…+55 °C
Beam angle
120 °
Cable length
500.000
Color rendering index Ra
> 90
Color temperature
6500 K
Conductor cross section
0.5 mm²
Construction wattage
21.00 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Dimmable
Yes 1)
Energy class of contained light source
E
GTIN
4058075707535
Height
1.50 mm
Input voltage range
23…25 V
LED pitch
6.94 mm
Length
5000.00 mm
Length – smallest unit
55.56 mm
Light color (designation)
Cold White
Light color LED
Cold White
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Lowest bending radius
30,0 mm
Luminous efficacy
130 lm/W
Luminous flux
2455 lm
Luminous flux per meter
545 lm
Maximum temperature at tc test point
80 °C
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting location
All surfaces
Nominal current
875 mA
Nominal lamp life time
50000 h
Nominal voltage
24 V
Nominal wattage
21.00 W
Nominal wattage per meter
4.2 W
Number of LEDs per meter
144
Number of LEDs per module
720
Number of LEDs per smallest unit
8
Packaging recyclability
Mostly recyclable packaging 1)
Prewired
Yes
Product recyclability
Mostly recyclable product 1)
Product weight
95.00 g
Protection class
III
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
Rated beam angle (half peak value)
120.00 °
Salt mist resistance acc. IEC 60068-2-52
No
Self-adhesive
Yes
Short pitch
Yes
Standard deviation of color matching
‹3 sdcm
Temperature range at storage
-20…+80 °C
Type of current
DC
Type of protection
IP00
UV resistance acc. IEC 60068-2-5
No
Width
8.00 mm
