PL-CN50-COB- 900-930-40D-G1
4052899541757
Ambient temperature range
-20…+40 °C
Beam angle
40 °
Cable length
500.000
Claimed equiv. conventional lamp power
50 W
Color rendering index Ra
≥90
Color temperature
3000 K
Construction wattage
12.30 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Diameter
50,0 mm
Dimmable
Yes
Energy consumption
13.55 kWh/1000h
Energy efficiency class
A+
GTIN
4052899541757
Height
52.00 mm
Input voltage range
34…37 V
Length
50.0 mm
Light color (designation)
Warm White
Light color LED
White
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Luminous efficacy
79 lm/W
Luminous flux
950 lm
Luminous intensity
1970 cd
Maximum temperature at tc test point
85 °C
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Nom. useful luminous flux 120° [PICOS]
950 lm
Nominal current
350.000 mA
Nominal lamp life time
50000 h
Nominal voltage
35.2 V
Nominal wattage
12.30 W
Number of LEDs per module
1
Number of switching cycles
100000
Packaging recyclability
Mostly recyclable packaging 1)
Performance temp. acc. to IEC 62717
75 °C
Product recyclability
Mostly recyclable product 1)
Product remark
Modules perfectly matched to OSRAM OPTOTRONIC® LED drivers (see relevant tabl
Product weight
90.00 g
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
Rated beam angle (half peak value)
40.00 °
Rated peak intensity
1970 cd
Standard deviation of color matching
≤3 sdcm
Standards
Acc. to IEC 624
Temperature range at storage
-40…80 °C
Temperature range in operation
-25…85 °C
Total useful luminous flux [PICOS]
980 lm
Type of current
DC
Type of protection
IP20
Warm-up time (60 %)
0.00 s
Width
50.00 mm
