PL-CN111-COB- 1800-930-24D-G1
4052899541412
Ambient temperature range
-25…+40 °C
Beam angle
24 °
Cable length
500.000
Claimed equiv. conventional lamp power
100 W
Color rendering index Ra
90
Color temperature
3000 K
Construction wattage
18.00 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Diameter
111,0 mm
Dimmable
Yes
Energy consumption
19.75 kWh/1000h
Energy efficiency class
A+
GTIN
4052899541412
Height
52.00 mm
Input voltage range
35…38 V
Length
111.0 mm
Light color (designation)
Warm White
Light color LED
White
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Luminous efficacy
105 lm/W
Luminous flux
1700 lm
Luminous intensity
9800 cd
Maximum temperature at tc test point
80 °C
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Nom. useful luminous flux 120° [PICOS]
1851 lm
Nominal current
500.000 mA
Nominal lamp life time
50000 h
Nominal voltage
36 V
Nominal wattage
18 W
Number of LEDs per module
1
Number of switching cycles
100000
Packaging recyclability
Mostly recyclable packaging 1)
Performance temp. acc. to IEC 62717
55 °C
Product color
White
Product recyclability
Mostly recyclable product 1)
Product remark
Modules perfectly matched to OSRAM OPTOTRONIC® LED drivers (see relevant tabl
Product weight
425.00 g
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
Rated beam angle (half peak value)
24.00 °
Rated peak intensity
9800 cd
Standard deviation of color matching
≤3 sdcm
Standards
Acc. to IEC 624
Temperature range at storage
-40…80 °C
Temperature range in operation
-25…80 °C
Total useful luminous flux [PICOS]
1880 lm
Type of current
DC
Type of protection
IP20
Warm-up time (60 %)
0.00 s
Width
111.00 mm
