DALI Magic
4052899039551
Product benefits
- DALI wizard software features (included)
- Intuitive configuration of up to 64 DALI electronic control gears
- Offline / Online configuration of DALI installations
- “DALI-Spy“-functionality for recording DALI line data flow
- Programming of OSRAM ECG
- Suitable for the shop floor environments
- Performs fast manual and automatic programming
- Easily enables the use of the pre-parameterization service
Tuner4TRONIC software features
Areas of application
- Configuration of DALI ECG functions
- Monitoring of DALI installations
Product features
- USB DALI converter for Tuner4TRONIC and DALI wizard software for Windows PC
- Pushbutton to test DALI dimming without need of connection to computer
- Powered by USB or by included universal power supply
- Integrated automatic DALI supply of up to 64 devices (up to 4 if powered by USB)
Equipment / Accessories
- Universal power supply (100…240 VAC, 5.9 VDC, 1.15 A, EU plug)
- USB cable (male A to male B), 180 cm
- Bipolar plug for DALI connection
References / Links
- Compatible software available at
Ambient temperature range
+15…+50 °C
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Dimmable
Yes
Dimming interface
DALI
GTIN
4052899039551
Height
28.00 mm
Length
120.0 mm
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Mains frequency
50/60 Hz
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Nominal voltage
220…240 V
Nominal wattage
7.00 W
Packaging recyclability
Mostly recyclable packaging 1)
Product color
White
Product recyclability
Mostly recyclable product 1)
Product weight
370.00 g
Protection class
1
Quantity of precious metals
0 mg
Quantity of rare earths
0 mg
Type of protection
IP20
Width
120.00 mm
