SIG 1227
4050300831718
Product benefits
- Much higher luminous efficacy than high-voltage signal lamps
- Clearly improved lamp quality due to higher gas pressure and inert gas filling
- Leads to reduced power consumption of the signal installation
- High resistance against shock and vibration compared to high-voltage lamps
- Max. premature failure rate: 2 % up to 4,400 h (related to lamp failures only)
- Retrofit for 230 V systems (replace lamp and reflector and install transformator)
Areas of application
- Road traffic signalling systems
Safety advice
- Use only in signal equipment/luminaires that are specially designed for the purpose.
Protect the lamps against moisture during operation and installation.
Base (standard designation)
BA20s
Burning position
s135
Color rendering index Ra
100
Construction wattage
22.00 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Design / version
Bulb
Diameter
36,0 mm
GTIN
4050300831718
Height
36,0 mm
Length
67.00 mm
Light center length (LCL)
31,0 mm 1)
Light color
10
Light source cap-type (or other electric interface)
BA20s
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Luminous efficacy
13 lm/W
Luminous flux
270 lm
Mercury content
0.0 mg
Mercury-free
Yes
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Nominal voltage
10 V
Nominal wattage
20 W
Order reference
1227
Overall length
67.00 mm
Packaging recyclability
Mostly recyclable packaging 1)
Product recyclability
Mostly recyclable product 1)
Product weight
18.1 g
Quantity of precious metals
0 mg
Quantity of rare earths
0 mg
Starting time
0 s
Width
36,0 mm
