LED Classic P 40 Filament DIM Energy efficiency class C S 2.9W 827 Clear E14
4099854066535
Product benefits
- Lamps with innovative LED "filament" technology
- Low energy consumption
- Design, dimensions, luminous flux comparable to a halogen lamp
- Instant 100 % light, no warm-up time
- Low flickering
Areas of application
- Perfect for decorative installations
- Domestic applications
- General illumination
- Outdoor use in outdoor luminaires only (minimum IP65)
Product features
- LED lamps for line voltage
- Very high efficiency of up to 162 lm/W
- Beam angle: up to 300°
- Very long lifetime of up to 50,000 h
- Very high number of switching cycles 500,000
- Dimmable
Safety advice
- Do not touch the lamp if broken.
- Must not be used if outer bulb is defective.
Ambient temperature range
-20…+40 °C
Anti-glare shield
No
Base (standard designation)
E14
Beam angle
300 °
Beam angle correspondence
SPHERE_360
Chromaticity coordinate x
0.463
Chromaticity coordinate y
0.420
Claim of equivalent power
Yes
Claimed equiv. conventional lamp power
40 W
Color rendering index Ra
80
Color temperature
2700 K
Color-tuneable light source
No
Connected light source (CLS)
No
Construction wattage
2.90 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Correlated colour temperature type
SINGLE_VALUE
Design / version
Clear
Diameter
45.00 mm
Dimmable
Yes 1)
Displacement factor
0.989
Energy consumption
3.00 kWh/1000h
Energy efficiency class
C 1)
Envelope
No
EPREL ID
1371386
Flickering metric (Pst LM)
≤1.0
GTIN
4099854066535
Height
45.00 mm
High luminance light source
No
Inrush current
1.86 A
LED light source replaces a fluorescent light source
No
Length
77.00 mm
Lifespan L70/B50 at 25 °C
50000 h
Light color
827
Light color (designation)
Warm White
Light source cap-type (or other electric interface)
E14
Lighting technology used
LED
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Lumen main.fact.at end of nom.life time
0.93
Lumen maintenance at end of service lifetime
0.93
Luminous efficacy
162 lm/W
Luminous flux
470 lm
Mains frequency
50/60 Hz
Mains or non-mains
MLS
Max. lamp number on MCB B10 A
108
Max. lamp number on MCB B16 A
174
Maximum diameter
45 mm
Maximum temperature at tc test point
Mercury content
0.0 mg
Mercury-free
Yes
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Model number
AC45265,AC45265
Networked standby power for CLS
not applicable
Nominal current
16 mA
Nominal voltage
220…240 V
Nominal wattage
2.9 W
Non-directional or directional
NDLS
Number of switching cycles
500000
Operating frequency
50/60 Hz
Operating mode
AC Mains
Order reference
LEDCLP40DIMEELC
Overall length
77.00 mm
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG0
Power factor λ
≥ 0.40
Product recyclability
Mostly recyclable product 1)
Product remark
All technical parameters apply to the entire la
Product weight
15.00 g
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
R9 Colour rendering index
1
Rated lamp survival factor at 6,000 h
≥ 0.90
Rated LLMF at 6,000 h
0.80
Standard deviation of color matching
≤6 sdcm
Standby power
0 W
Starting time
< 0.5 s
Stroboscope effect metric (SVM)
≤0.4
Survival factor
0.90
Temperature range at storage
-20…+80 °C
Total harmonic distortion
125.43 %
Type of current
AC
Type of protection
IP20
Warm-up time (60 %)
‹ 0.50 s
Width
45.00 mm
