DULUX LED SQ28 EM 2 PINS VALUE 13W 835 GR8
4058075822597
Product benefits
- Easy installation
- Low energy consumption
- Easy relamping thanks to compact design
- Operation directly on 230 V AC mains possible
Areas of application
- General illumination within ambient temperatures from -20…+45 °C
- Supermarkets and department stores
- Walkways and corridors
- Hotels, restaurants
Product features
- LED replacement for conventional compact fluorescent lamps for use in CCG luminaires or on AC mains
- Lifetime up to 30,000 h
- Single-ended two-pin plug-in GR8 base
- Type of protection: IP20
- Mercury-free lamps
Safety advice
- Not suitable for tandem operation.
- The operating temperature range of DULUX LED is restricted. In case of doubt regarding suitability of the application please measure Tc temperature on the product prior to installation.
- All electrical connections must be made by a qualified person.
- Do not touch the lamp with bare fingers.
- Must not be used if outer bulb is defective.
- Lamp not suitable for emergency operation.
Ambient temperature range
-20…+45 °C 1)
Anti-glare shield
No
Base (standard designation)
GR8
Beam angle
130 °
Beam angle correspondence
SPHERE_360
Chromaticity coordinate x
0.407
Chromaticity coordinate y
0.392
Claim of equivalent power
No
Claimed equiv. conventional lamp power
28 W
Color rendering index Ra
80
Color temperature
3500 K
Color-tuneable light source
No
Connected light source (CLS)
No
Construction wattage
13.00 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Additional info can be provided per individual request
Correlated colour temperature type
SINGLE_VALUE
Design / version
Frosted
Diameter
202.00 mm
Dimmable
No
Displacement factor
0.90
Energy consumption
13.00 kWh/1000h
Energy efficiency class
F 1)
Envelope
No
EPREL ID
1404787,2059898
Flickering metric (Pst LM)
1.0
GTIN
4058075822597
Height
202.00 mm
High luminance light source
No
Input voltage DC
186…260 V 1)
Inrush current
6 A
LED light source replaces a fluorescent light source
No
Length
204.00 mm
Lifespan L70/B50 at 25 °C
30000 h
Light color
835
Light color (designation)
Warm White
Light source cap-type (or other electric interface)
GR8
Lighting technology used
LED
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Lumen main.fact.at end of nom.life time
0.70
Lumen maintenance at end of service lifetime
0.70
Luminous efficacy
103 lm/W
Luminous flux
1350 lm
Mains frequency
50/60 Hz
Mains or non-mains
MLS
Max. lamp number on MCB B10 A
75
Max. lamp number on MCB B10 A - CCG with compensation
20
Max. lamp number on MCB B10 A - CCG without compensation
30
Max. lamp number on MCB B16 A
120
Max. lamp number on MCB B16 A - CCG with compensation
30
Max. lamp number on MCB B16 A - CCG without compensation
48
Maximum diameter
19 mm
Maximum temperature at tc test point
70 °C
Mercury content
0.0 mg
Mercury-free
Yes
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Model number
AC46465,AC64991,AC64991
Nominal current
57 mA
Nominal voltage
220…240 V
Nominal wattage
13 W
Non-directional or directional
NDLS
Number of switching cycles
200000
Operating frequency
50/60 Hz
Operating mode
CCG, AC Mains
Order reference
DULUX LED SQ28
Overall length
204.00 mm
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG0
Product recyclability
Mostly recyclable product 1)
Product weight
132.00 g
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
R9 Colour rendering index
1
Standard deviation of color matching
≤6 sdcm
Standby power
0 W
Starting time
< 0.5 s
Stroboscope effect metric (SVM)
0.4
Suitable for DC input
Yes
Survival factor
0.90
Temperature range at storage
-20…+80 °C
Total harmonic distortion
≤ 30 %
Tube diameter
19,0 mm
Type of current
AC
Type of protection
IP20
Width
202.00 mm
