DULUX LED SQ SENSOR
4099854795169
Product benefits
- Suitable for built-in DULUX LED SQ lamp
- Plug & Upgrade concept to extend the On/Off lamp to a sensor lamp
- Multiple sensor settings by DIP switch: range, daylight detection, hold time and DIM-level /-period
Areas of application
- Low-profile wall and ceiling luminaires
- Public buildings, reception areas, offices, corridors, etc.
Product features
- Microwave sensor with 5,8 GHz
- Combined daylight and motion detection
- Indoor use only, not suitable for outdoor use
- Detection area of the sensor can be adjusted 100 % or 50 %
- Ambient temperature in operation: -25…+60 °C
Safety advice
- All electrical connections must be made by a qualified person.
Ambient temperature range
-25…+60 °C
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Dimmable
No
GTIN
4099854795169
Height
15.50 mm
Length
63.35 mm
Lifespan L70/B50 at 25 °C
30000 h
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Mains frequency
0 Hz
Maximum temperature at tc test point
85 °C
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Nominal current
16 mA
Nominal voltage
7.5…13 V
Nominal wattage
0.21 W
Order reference
DULUX LED SQ SE
Packaging recyclability
Mostly recyclable packaging 1)
Product recyclability
Mostly recyclable product 1)
Product remark
Available from June 2026
Product weight
10.00 g
Temperature range at storage
-20…+80 °C
Type of current
DC
Type of protection
IP20
Width
25.10 mm
