NAV-T 1000 W E40
4050300251417
Product benefits
- High luminous efficacy
Areas of application
- Streets
- Outdoor lighting
- Industrial installations
- Suitable for use in open and enclosed luminaires
- Outdoor applications only in suitable luminaires
Product features
- Service lifetime: 3 years (at approx. 11 h/day)
Safety advice
- Disconnect mains before installation.
- Must not be used if outer bulb is defective.
Base (standard designation)
E40
Burning position
Any
Color rendering index Ra
≤25
Color temperature
2000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Additional info can be provided per individual request
Design / version
Clear
Diameter
66.00 mm
Dimmable
Yes
Enclosed luminaire required
No
Energy consumption
1003.00 kWh/1000h
GTIN
4050300251417
Ignition voltage
3.6/5.0 kVp 1)
ILCOS
ST-1000-H/E/SL-E40-66/360
Length
352.00 mm
Lifespan B10
11000 h
Lifespan B5
8000 h
Lifespan B50
20000 h
Light center length (LCL)
240,0 mm
Light color
220
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Luminous efficacy
135 lm/W
Luminous flux
130000 lm
Maximum permitted base edge temperature
250 °C
Maximum permitted outer bulb temperature
400 °C
Mercury content
39.1 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Nominal current
10700 mA
Nominal voltage
110 V
Nominal wattage
1000 W
Operating mode
Conventional control gear (CCG) and ignitor
Order reference
NAV-T 1000W E40
Overall length
352.00 mm
Packaging recyclability
Mostly recyclable packaging 1)
PFC capacitor at 50 Hz
100 µF
Product recyclability
Mostly recyclable product 1)
Product remark
Not for general lighting
Product weight
304.8 g
Quantity of precious metals
0 mg
Quantity of rare earths
0 mg
Rated lamp survival factor at 12,000 h
0.87
Rated lamp survival factor at 16,000
0.74
Rated lamp survival factor at 2,000 h
0.99
Rated lamp survival factor at 20,000 h
0.50
Rated lamp survival factor at 4,000 h
0.98
Rated lamp survival factor at 6,000 h
0.95
Rated lamp survival factor at 8,000 h
0.92
Rated LLMF at 12,000 h
0.86
Rated LLMF at 16,000 h
0.80
Rated LLMF at 2,000 h
0.98
Rated LLMF at 20,000 h
0.78
Rated LLMF at 4,000 h
0.95
Rated LLMF at 6,000 h
0.93
Rated LLMF at 8,000 h
0.91
UV protection
No
