DULUX D/E 10 W/827
4050300012124
Product benefits
- Improved maintenance
Areas of application
- Offices, public buildings
- Shops
- Supermarkets and department stores
- Hotels, restaurants
- Industry
Product features
- Good color rendering index
- Dimmable (3…100 %)
- Short and compact pin-base lamp with double-turn tubes
- Single-ended four-pin plug-in G24q base
Equipment / Accessories
- Suitable for operation on electronic control gear
Safety advice
- In case of lamp breakage:
Ambient temperature range
-5…+40 °C
Anti-glare shield
No
Base (standard designation)
G24q-1
Beam angle correspondence
SPHERE_360
Chromaticity coordinate x
0,455
Chromaticity coordinate y
0,415
Claim of equivalent power
No
Color rendering index Ra
≥80
Color temperature
2700 K
Color-tuneable light source
No
Connected light source (CLS)
No
Construction wattage
10.70 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Correlated colour temperature type
SINGLE_VALUE
Diameter
12.0 mm
Dimmable
Yes
Energy consumption
11.00 kWh/1000h
Energy efficiency class
G
Envelope
No
EPREL ID
546439
GTIN
4050300012124
Height
12.0 mm
High luminance light source
No
ILCOS
FSQH-10/827-/P/-G24q-1
Length
103.00 mm
Length with base excl. base pins/connection
87,00 mm
Lifespan B50
20000 h
Light color
827
Light color (designation)
LUMILUX INTERNA
Light source cap-type (or other electric interface)
G24q-1
Lighting technology used
CFLNI
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Luminous efficacy
56 lm/W
Luminous flux
600 lm
Mains or non-mains
NMLS
Mercury content
1.6 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Model number
AC34214
Nominal current
0.19 A
Nominal voltage
64 V
Nominal wattage
10 W
Non-directional or directional
NDLS
Order reference
DULUX D/E 10W/8
Overall length
103.00 mm
Packaging recyclability
Mostly recyclable packaging 1)
Product recyclability
Mostly recyclable product 1)
Product weight
28.5 g
Quantity of precious metals
0 mg
Quantity of rare earths
0 mg
Rated lamp survival factor at 12,000 h
0.95
Rated lamp survival factor at 16,000
0.81
Rated lamp survival factor at 2,000 h
0.99
Rated lamp survival factor at 20,000 h
0.50
Rated lamp survival factor at 4,000 h
0.99
Rated lamp survival factor at 6,000 h
0.99
Rated lamp survival factor at 8,000 h
0.99
Rated LLMF at 12,000 h
0.79
Rated LLMF at 16,000 h
0.78
Rated LLMF at 2,000 h
0.90
Rated LLMF at 20,000 h
0.77
Rated LLMF at 4,000 h
0.84
Rated LLMF at 6,000 h
0.83
Rated LLMF at 8,000 h
0.81
Service life
13000 h
Tube diameter
12 mm
Width
12.0 mm
