SMART+ ZIGBEE Compact Outdoor Plug EU
4099854419317
Product benefits
- Integrates conventional electric equipment into compatible smart home systems
- Enables switching of conventional light sources and other electric devices
- Fit for outdoor use with IP44, the protection against splash water
- Simple connection of electric devices via standard socket
- Monitors energy usage of connected devices or tracks the energy generation of small solar systems
Areas of application
- Wherever non-smart devices need to be integrated into compatible smart home systems
- Gardens, balconies and other outdoor areas
- To measure the energy generation of small solar systems
Product features
- Control via compatible smart home system (gateway and app) or on/off button on the device
- Control via voice control available: Google Home or Amazon Alexa, depending on the smart home system in use
- Type of protection: IP44
- Energy meter
- Scheduling
- Network protocol: ZigBee 3.0
- For full functionality connection to a compatible smart home System (gateway and app) required
- High switching power: up to 3,680 W / 16 A
Safety advice
- Disconnect devices which generate heat from the mains, after use in order to avoid them being accidentally switched on.
- Very high capacitive and inductive loads may in some cases lead to destruction of the device or reduction in the number of switching cycles.
- Do not use the SMART+ Plug in conjunction with medical equipment.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
- To be connected to an automatic circuit breaker (max. 16 A).
References / Links
- Further information and frequently asked questions (FAQs) at
Ambient temperature range
-20…+35 °C
Compatible smart home technology
Amazon Ale
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
GTIN
4099854419317
Height
101.0 mm
Length
57 mm
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Mains frequency
50 Hz
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Network protocol
ZigBee
Nominal current
16 A
Nominal voltage
230 V
Number of switching cycles
10000
Operating mode
Mains voltage
Packaging recyclability
Mostly recyclable packaging 1)
Product color
Black
Product recyclability
Mostly recyclable product 1)
Product weight
111.00 g
Protection class
I
Standards
CE
Type of connection
Plug type E & F
Type of connection, output side
Socket type F
Type of protection
IP44
Width
73 mm
