Floodlight Essential Sensor 150W 4000K
4099854429958
Product benefits
- IP65 protection is suitable for outdoor application (for sensor types 100W, 150W, 200W: IP44, the protection against splash water)
- White satin-frosted diffuser for uniform glare-free light
- Demand based lighting and energy saving thanks to motion and daylight sensor
Areas of application
- Outdoor
- Building facades
Product features
- Type of protection, luminaire head and housing: IP65, Type of protection, Sensor: up to IP65
- Adjustable light angle
Equipment / Accessories
- Connection cable included
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
- To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be effectively fixed to the wall if the wiring is within arm’s reach.
- Check wall-ceiling for suitability. If uncertain, seek professional advice.
Ambient temperature range
-20…+40 °C
Beam angle
110 °
Body material
Aluminum
Cable length
250 mm
Color rendering index Ra
> 80
Color temperature
4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Cover material
Glass
Dimmable
No
Glow Wire Test according to IEC 60695-2-12
650 °C
GTIN
4099854429958
Height
310.00 mm
Housing color
Black
Inrush current time Th50
136 µs
Length
337.00 mm
Lifespan L70/B50 at 25 °C
25000 h 1)
Light color (designation)
Cool White
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Luminaire with limited surface temperature, "D sign"
No
Luminous efficacy
100 lm/W
Luminous flux
15000 lm
Mains frequency
50…60 Hz
Max. number of luminaires per miniature circuit breaker B16
16
Max. number of luminaires per miniature circuit breaker C16
16
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting type
Surface
Nominal current
675.000 mA
Nominal voltage
220…240 V
Nominal wattage
150.00 W
Number of illuminants
empty
Number of switching cycles
12500
Operating mode
Integrated LED driver
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG0
Power factor λ
> 0.90
Product color
Black
Product recyclability
Mostly recyclable product 1)
Product weight
1580.00 g
Protection class
I
Protection class IK (shock resistance)
IK06
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Sensor technology
Passive infrared (PIR)
Standard deviation of color matching
6 sdcm
Temperature range at storage
-25…+80 °C
Total harmonic distortion
< 20 %
Total luminous flux of contained light sources
17000 lm
Type of connection
Cable, 3-pole
Type of protection
IP44
Type of sensor
Moti
Width
45.00 mm
With light source
Yes
