Floodlight EA 10W 840 Dark Grey
4099854429491
Product benefits
- Very low energy consumption
- Quick and simple installation thanks to low profile, compact and light weight design
Areas of application
- Outdoor
- Garages
- Building facades
Product features
- Luminous efficacy of light source: up to 210 lm/W
- Very bright and functional outdoor LED luminaires
- Type of protection: IP65
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
Adjustable
Yes
Ambient temperature range
-20…+40 °C
Application environment
Outdoor
Beam angle
95 °
Body material
Aluminum
Cable length
1000 mm
Color rendering index Ra
> 80
Color temperature
4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Cover material
Glass
Dimmable
No
Glow Wire Test according to IEC 60695-2-12
650 °C
GTIN
4099854429491
Height
123.00 mm
Housing color
Black
Inrush current time Th50
85.5 µs
Length
128.00 mm
Lifespan L70/B50 at 25 °C
50000 h 1)
Light color (designation)
Cool White
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Luminaire with limited surface temperature, "D sign"
No
Luminous efficacy
175 lm/W
Luminous flux
1750 lm
Mains frequency
50…60 Hz
Max. number of luminaires per miniature circuit breaker B16
72
Max. number of luminaires per miniature circuit breaker C10
57
Max. number of luminaires per miniature circuit breaker C16
92
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting type
Surface
Nominal current
76.000 mA
Nominal voltage
220…240 V
Nominal wattage
10.00 W
Number of illuminants
empty
Number of switching cycles
25000
Operating mode
Mains voltage
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG1
Power factor λ
≥0.5
Product color
Black
Product recyclability
Mostly recyclable product 1)
Product weight
371.00 g
Protection class
I
Protection class IK (shock resistance)
IK06
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Standard deviation of color matching
6 sdcm
Temperature range at storage
-20…+80 °C
Total harmonic distortion
≤ 140 %
Total luminous flux of contained light sources
2100 lm
Type of connection
Cable, 3-pole
Type of protection
IP65
Width
32.00 mm
With light source
Yes
