ENDURA® Style USB Wall Step Wide Sensor IP44 Dark Grey
4099854699870
Product benefits
- Battery-powered outdoor luminaire
- Easy and quick installation, independent from connection to power supply
- Easily detachable from the wall for charging thanks to slide-up mounting plate
- Energy-efficient thanks to LED technology
Areas of application
- Outdoor
- Entrance lighting
- Patios, balconies
- General illumination
- Facade and building illumination
- Garage, barn, attic, basement
Product features
- Integrated rechargeable lithium battery which can be charged via USB cable
- Operating time with fully charged battery: up to 2,5 months (depending on the model, work mode and conditions)
- Charging time: Up to 5,5 h
- 2 different work modes: Mode 1: 100% light for 30 seconds when motion detected (dusk-to-dawn); Mode 2: Non-sensor mode-100% light constantly ON
- Diffuser made of opal polycarbonate
- Type of protection: IP44
- PIR motion detection and daylight sensor, matching with housing color
- Lower light smog, on-demand lighting (sensor version)
Equipment / Accessories
- Mounting accessories included
- USB-C charging cable (cable length: 1.0 m) included
Safety advice
- If the battery compartment (if applicable) does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
- Please avoid: Maximal ambient temperature: +40 °C. Replacement of a battery with an incorrect type that can defeat safeguard (for example, in the case of some lithium battery types). Altitude during operation: 2000 m. Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion.
Ambient temperature range
0…+40 °C
Application environment
Outdoor
Ball shot safe
No
Battery charging time
5.5 h
Battery size [GMS]
Others
Beam angle
55 °
Body material
Plastic
Color rendering index Ra
≥80
Color temperature
3000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Cover material
Plastic
Detection range of motion sensor
3…5 m
Detection threshold of daylight sensor
10…100 lx
Dimmable
No
Glow Wire Test according to IEC 60695-2-12
650 °C
GTIN
4099854699870
Height
102.00 mm
Housing color
Dark grey
Length
174.00 mm
Lifespan L70/B50 at 25 °C
25000 h 1)
Light color (designation)
Warm White
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Luminous flux
110 lm
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting location
Wall
Mounting type
Surface
Nominal capacity of battery
1800 mAh
Nominal current
370.000 mA
Nominal voltage
5 DC V
Nominal voltage of battery
3.7 V
Nominal wattage
1.50 W
Number of included batteries
1
Number of switching cycles
12500
Operating mode
Battery
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG1
Power factor λ
1.00
Product color
Dark grey
Product recyclability
Mostly recyclable product 1)
Product weight
220.00 g
Protection class
III
Protection class IK (shock resistance)
IK03
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Sensor controlled switching time
30 s
Sensor detection angle
100 °
Sensor technology
Passive infrared (PIR)
Temperature range at storage
-20…+80 °C
Total luminous flux of contained light sources
160 lm
Type of Battery
Lithium ion
Type of protection
IP44
Type of sensor
Lig
Width
67.00 mm
With light source
Yes
