Submarine 2 x 7W 4000K
4099854429132
Product benefits
- Energy savings of up to 65 % comp. to luminaires using T8 fluorescent lamps on CCG
- Easy installation thanks to improved space for mounting brackets and easy to open tray
- Quick and easy lamp replacement
- Extremely break resistant SubstiTUBE Star PC LED-Tube included
- Good, even illumination
Areas of application
- Basements, garages, warehouses
- For indoor use only
Product features
- Damp-proof luminaire with LED tube for mains voltage operation
- Durable and energy-saving LED luminaire
- Dust-protected and jet-proof (IP65)
- Mercury-free and RoHS compliant
- M20 cable gland for 8-12 mm cables
- Not dimmable
Equipment / Accessories
- SubstiTUBE STAR PC EM are delivered with the product
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
Ambient temperature range
-20…+30 °C
Application environment
Indoor
Beam angle
120 °
Body material
Acrylonitrile butadiene styrene (ABS)
Color rendering index Ra
≥80
Color temperature
4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Cover material
Polycarbonate (PC)
Dimmable
No
Glow Wire Test according to IEC 60695-2-12
650 °C
GTIN
4099854429132
Height
75.00 mm
Holder designation
G13
Housing color
Gray
Length
651.00 mm
Lifespan L70/B50 at 25 °C
30000 h 1)
Light color (designation)
Cool White
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Luminaire with limited surface temperature, "D sign"
No
Luminous efficacy
93 lm/W
Luminous flux
1300 lm
Mains frequency
50…60 Hz
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting type
Surface
Nominal current
65.000 mA
Nominal voltage
220…240 V
Nominal wattage
14.00 W
Number of illuminants
2
Number of switching cycles
100000
Operating mode
Mains voltage
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG0
Product color
Gray
Product recyclability
Mostly recyclable product 1)
Product weight
900.00 g
Protection class
I
Protection class IK (shock resistance)
IK06
Replaceable light source
Yes
Standard deviation of color matching
≤6 sdcm
Total harmonic distortion
≤ 20 %
Total luminous flux of contained light sources
1600 lm
Type of connection
Terminal, 3-Pole (L, N, PE)
Type of protection
IP65
Width
105.00 mm
With light source
Yes
