Linear Flat Socket USB 540mm 10W 840
4099854462559
Product benefits
- Multifunctional Use: Lighting and Power / Charging Function in one Luminaire
- Power socket with two USB ports to support additional equipment (kitchen devices, mobile devices)
Areas of application
- Kitchens
- Living areas
- Undercabinet lighting
Product features
- Power Socket can support equipment with up to 1000 W
- Two USB charging ports
Equipment / Accessories
- Mounting clips included
Safety advice
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
- To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be effectively fixed to the wall if the wiring is within arm’s reach.
- Check wall-ceiling for suitability. If uncertain, seek professional advice.
Application environment
Indoor
Beam angle
120 °
Body material
Aluminum|Plastic
Color rendering index Ra
> 80
Color temperature
4000 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Dimmable
No
Glow Wire Test according to IEC 60695-2-12
650 °C
GTIN
4099854462559
Height
41.50 mm
Housing color
White
Length
540.00 mm
Lifespan L70/B50 at 25 °C
30000 h 1)
Light color (designation)
Cool White
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Luminaire with limited surface temperature, "D sign"
No
Luminous efficacy
80 lm/W
Luminous flux
800 lm
Mains frequency
50…60 Hz
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting type
Surface
Nominal current
195.000 mA
Nominal voltage
220…240 V
Nominal wattage
10.00 W
Operating mode
Integrated LED driver
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG1
Power factor λ
> 0.5
Product color
White
Product recyclability
Mostly recyclable product 1)
Product weight
665.00 g
Protection class
I
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Standard deviation of color matching
6 sdcm
Standards
CE
Total luminous flux of contained light sources
1100 lm
Type of connection
Plug type F
Type of emergency operation test
None
Type of protection
IP20
Width
81.00 mm
With light source
Yes
