Highbay UFO Sensor 130 W 765 IP65 Black
4058075858473
Product benefits
- E27 Ceiling light with adjustable light-panels
- Easy installation in E27 lamp holders
- Perfect match for renovation purposes
- If turn product off/on 4 times, the sensor function can be switched off
Areas of application
- Renovation
- Living areas (living rooms, dining rooms, bedrooms etc.)
- Hallways and staircases
Product features
- Built-in PIR Motion sensor
- Type of protection: IP20
Safety advice
- Check wall-ceiling for suitability. If uncertain, seek professional advice.
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
Ambient temperature range
-20…+40 °C
Application environment
Outdoor
Ball shot safe
No
Beam angle
110 °
Body material
Aluminum
Color rendering index Ra
> 70
Color temperature
6500 K
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Cover material
Glass
Detection range of motion sensor
6…10 m
Dimmable
No
Flickering metric (Pst LM)
Glow Wire Test according to IEC 60695-2-12
650 °C
GTIN
4058075858473
Height
83.00 mm
Housing color
Black
Inrush current
95 A
Inrush current time Th50
68 µs
Length
273.00 mm
Lifespan L70/B50 at 25 °C
20000 h 1)
Light color (designation)
Cool Daylight
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Luminaire with limited surface temperature, "D sign"
No
Luminous efficacy
115 lm/W
Luminous flux
15000 lm
Mains frequency
50…60 Hz
Max. number of luminaires per miniature circuit breaker B16
2
Max. number of luminaires per miniature circuit breaker C10
2
Max. number of luminaires per miniature circuit breaker C16
4
Mercury content
0.0 mg
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Mounting location
Ceiling
Mounting type
Surface
Nominal current
590.000 mA
Nominal voltage
220…240 V
Nominal wattage
130.00 W
Number of switching cycles
25000
Operating mode
Mains voltage
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG1
Power factor λ
> 0.90
Product color
Black
Product recyclability
Mostly recyclable product 1)
Product weight
1420.00 g
Protection class
I
Protection class IK (shock resistance)
IK05
Replaceable light source
No
Replaceable light source (EPREL)
Not replaceable
Sensor controlled switching time
30 s
Sensor detection angle
120 °
Sensor technology
Microwave
Standard deviation of color matching
6 sdcm
Stroboscope effect metric (SVM)
Temperature range at storage
-20…+80 °C
Total harmonic distortion
< 20 %
Total luminous flux of contained light sources
15500 lm
Type of connection
Terminal, 3-Pole (L, N, PE)
Type of emergency operation test
None
Type of protection
IP65
Type of sensor
Motion
Width
273.00 mm
With light source
Yes
