LED TUBE T9 C 40 EM 24W 865 G10q
4099854042744
Product benefits
- Quick, simple and safe replacement without rewiring
- Energy savings of up to 50% (compared to T9 fluorescent lamp on CCG)
- Also suitable for operation at low temperatures
Areas of application
- General illumination within ambient temperatures from -20…+45 °C
- Corridors, stairways, parking garages
- Domestic applications
- Decorative applications
Product features
- LED alternative to classic T9 fluorescent lamps in CCG luminaires
- Uniform illumination
- Lifetime up to 30,000 h
- Mercury-free and RoHS compliant
Legal advice
- When used to replace a T9 fluorescent lamp the total energy efficiency and light distribution depends on the design of the lighting system.
Safety advice
- Not suitable for operation with electronic control gear.
- Operation in outdoor applications in suitable damp-proof luminaires possible according to data sheet and installation instruction.
- All electrical connections must be made by a qualified person.
- Disconnect mains before installation.
- Not suitable for emergency lighting.
- Do not touch the lamp if broken.
- Must not be used if outer bulb is defective.
References / Links
- For current information see
Ambient temperature range
-20…+45 °C 1)
Anti-glare shield
No
Base (standard designation)
G10q
Beam angle
110 °
Beam angle correspondence
SPHERE_360
Chromaticity coordinate x
0.3123
Chromaticity coordinate y
0.3282
Claim of equivalent power
Yes
Color rendering index Ra
≥80
Color temperature
6500 K
Color-tuneable light source
No
Connected light source (CLS)
No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
Yes
Correlated colour temperature type
SINGLE_VALUE
Diameter
400.00 mm
Dimmable
No
Displacement factor
0.9
Energy consumption
24.00 kWh/1000h
Energy efficiency class
E 1)
Envelope
No
EPREL ID
1340163
Flickering metric (Pst LM)
1
GTIN
4099854042744
Height
400.00 mm
High luminance light source
No
Inrush current
16 A
LED light source replaces a fluorescent light source
No
Length
400.00 mm
Lifespan L70/B50 at 25 °C
30000 h
Light color
865
Light color (designation)
Cool Daylight
Light source cap-type (or other electric interface)
G10q
Lighting technology used
LED
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
List of substances of very high concern in concentrations greater than 0.1% in mass percentage
Lead (7439-92-1)
Lumen main.fact.at end of nom.life time
0.96
Lumen maintenance at end of service lifetime
0.96
Luminous efficacy
120 lm/W
Luminous flux
2900 lm
Mains frequency
50/60 Hz
Mains or non-mains
MLS
Max. lamp number on MCB B10 A
16
Max. lamp number on MCB B10 A - CCG with compensation
11
Max. lamp number on MCB B10 A - CCG without compensation
37
Max. lamp number on MCB B16 A
19
Max. lamp number on MCB B16 A - CCG with compensation
14
Max. lamp number on MCB B16 A - CCG without compensation
66
Maximum temperature at tc test point
75 °C
Mercury content
0.0 mg
Mercury-free
Yes
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Model number
AC45085,AC45085
Nominal current
107 mA
Nominal voltage
220…240 V
Nominal wattage
24 W
Non-directional or directional
NDLS
Number of switching cycles
200000
Operating frequency
50/60 Hz
Operating mode
Conventional control gear (CCG), AC Mains
Order reference
LEDTUBE T9C EM
Overall length
400.00 mm
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG0
Power factor λ
> 0.90
Product recyclability
Mostly recyclable product 1)
Product weight
290.00 g
Quantity of precious metals
Contains at least 10 mg
Quantity of rare earths
Contains at least 1 mg
R9 Colour rendering index
1
Rated lamp survival factor at 6,000 h
≥ 0.90
Rated LLMF at 6,000 h
0.80
Standard deviation of color matching
≤6 sdcm
Starting time
< 0.5 s
Stroboscope effect metric (SVM)
0.4
Survival factor
0.9
Temperature range at storage
-20…+80 °C
Total harmonic distortion
< 20 %
Type of current
AC
Type of protection
IP20
Warm-up time (60 %)
0.00 s
Width
400.00 mm
