LED Line 60 140° 310mm 9W 827 Frosted S19
4099854059674
Product benefits
- Long life
- Lower energy consumption than incandescent or halogen lamps
- No UV and near-IR radiation in the light beam
- Three year guarantee
Areas of application
- Domestic applications
- Outdoor use in suitable outdoor luminaires only
Product features
- LED alternative to conventional lamps
- Mercury-free lamps
Safety advice
- Do not touch the lamp if broken.
- Must not be used if outer bulb is defective.
References / Links
- For dimming conformity see
- For Guarantee see
Ambient temperature range
-20…+40 °C
Anti-glare shield
No
Base (standard designation)
S19 s
Beam angle
140 °
Beam angle correspondence
SPHERE_360
Chromaticity coordinate x
0,458
Chromaticity coordinate y
0,410
Claim of equivalent power
Yes
Claimed equiv. conventional lamp power
60 W
Color rendering index Ra
≥80
Color temperature
2700 K
Color-tuneable light source
No
Connected light source (CLS)
No
Construction wattage
9.00 W
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage
No
Correlated colour temperature type
SINGLE_VALUE
Design / version
Frosted
Diameter
38.00 mm
Dimmable
No
Displacement factor
0.5
Energy consumption
9.00 kWh/1000h
Energy efficiency class
F 1)
Envelope
No
EPREL ID
522865
Flickering metric (Pst LM)
1
GTIN
4099854059674
Height
38.00 mm
High luminance light source
No
Inrush current
0.2 A
LED light source replaces a fluorescent light source
No
Length
310.00 mm
Lifespan L70/B50 at 25 °C
15000 h
Light color
827
Light color (designation)
Warm White
Light source cap-type (or other electric interface)
S19 s
Lighting technology used
LED
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage
No
Lumen main.fact.at end of nom.life time
0.70
Lumen maintenance at end of service lifetime
0.70
Luminous efficacy
92 lm/W
Luminous flux
830 lm
Mains frequency
50/60 Hz
Mains or non-mains
NMLS
Max. lamp number on MCB B10 A
100
Max. lamp number on MCB B16 A
160
Maximum diameter
38 mm
Maximum temperature at tc test point
70 °C
Mercury content
0.0 mg
Mercury-free
Yes
Minimum percentage of recycled content in the product
0 % 1)
Minimum rate of recycled material in packaging
80 % 1)
Model number
AC32110,AC32110
Nominal current
50 mA
Nominal useful luminous flux 90°
830 lm
Nominal voltage
220…240 V
Nominal wattage
9 W
Non-directional or directional
NDLS
Number of switching cycles
100000
Operating frequency
50/60 Hz
Operating mode
AC Mains
Order reference
LINE S19 9W/827
Overall length
310.00 mm
Packaging recyclability
Mostly recyclable packaging 1)
Photobiological safety group acc. to EN62778
RG0
Power factor λ
‹ 0.70
Product recyclability
Mostly recyclable product 1)
Product remark
All technical parameters apply to the entire la
Product weight
52.00 g
R9 Colour rendering index
1
Rated lamp survival factor at 6,000 h
≥ 0.90
Rated LLMF at 6,000 h
0.80
Standard deviation of color matching
≤6 sdcm
Standby power
1 W
Starting time
< 0.5 s
Stroboscope effect metric (SVM)
0.4
Survival factor
0.90
Temperature range at storage
-20…+80 °C
Total harmonic distortion
80 %
Type of current
AC
Type of protection
IP20
Warm-up time (60 %)
‹ 0.50 s
Width
38.00 mm
